Mechatronics & Robotics Lab
Where Mechanics Meets Electronics Meets Code.
The EdNex Mechatronics & Robotics Lab introduces students to the integrated world of mechanical systems, electronics, sensors, actuators, and software — giving them the multi-disciplinary skills demanded by modern manufacturing and automation industries.
Lab Modules
Sensors & Actuators Materials Lab
- Sensor kit — proximity, optical, ultrasonic, temperature, pressure, force
- Actuator trainers — stepper motors, servo motors, pneumatic cylinders
- Signal conditioning and data acquisition (DAQ) modules
Embedded Systems & Microcontrollers
- Arduino and Raspberry Pi development boards
Industrial Automation Basics
- PLC trainer stations — INTELITEK, DOBOT
- Conveyor belt and sorting system model
- Pick & place simulation with pneumatic arm
Robotics
- 6-axis collaborative robot arm (cobot) — 3–5 kg payload
- Mobile robot platform — line following, obstacle avoidance, mapping
- Robot simulation software — ROS (Robot Operating System) / V-REP
- End-effector kit — gripper, suction cup, camera
Vision & AI-Assisted Systems
- Machine vision camera and lighting kit
- Image processing with OpenCV on Raspberry Pi
- Defect detection and quality control model system
Equipment Specification Summary
Equipment / System | Details |
Collaborative Robot Arm | |
PLC Trainer | |
Mobile Robot Platform | |
DAQ Module | |
Machine Vision Camera | |
Cobot Programming Kit |
Curriculum Alignment
- Sensors, Transducers & Signal Conditioning (Year 2)
- Embedded Systems & Microprocessors (Year 2–3)
- Programmable Logic Controllers & Automation (Year 3)
- Robotics & Computer Vision (Year 3–4)
- Capstone Automation Project (Year 4)
